BA215
House amplifier
up to 1006 MHz, gain 43 dB, level CTB/CSO 116 dBµV
|
Ordering number 02505 |
Specifications
|
T Y P E |
BA215 |
||||
|
Ordering number |
02505 |
||||
|
Frequency range |
47-1006 MHz |
||||
|
Gain |
43 dB |
||||
|
Flatness |
± 0.5 dB |
||||
|
Gain adjustment |
18 dB |
||||
|
Slope adjustment |
18 dB |
||||
|
Interstage attenuator |
0/3/6/9 dB |
||||
|
Interstage equalizer |
0/3/6/9 dB |
||||
|
Output level CTB, CSO (EN60728-3)* |
116 dBµV (42 ch.) |
||||
|
Input and output return loss |
≥ 18 dB at 40 MHz - 1.5 dB/octave |
||||
|
Noise figure |
< 5 dB |
||||
|
Test point |
- 30 dB |
||||
|
Power consumption |
230 V~ 50/60 Hz 13 W |
||||
|
Operating temperature range |
-20°C ÷ +50°C |
||||
|
Dimensions |
180x132x76 mm (main body); 213x132x76 mm (with fixing ears) |
||||
|
Weight (packed) |
1.4 kg |
* measured with 6 dB interstage equalizer
